Principle of Composite Chamber Slightly Superheated Steam Generator
The composite chamber micro-superheated steam generator employs water-cooled fully premixed flat-surface combustion technology to achieve highly efficient, low-consumption steam production. Its core operational mechanism involves the coordinated functioning of three major systems: combustion, water flow, and flue gas.
Within the combustion system, fuel gas and air pressurized by the blower are thoroughly mixed in the air mixer. After being streamlined by the air distribution plate, the mixture ignites on the surface of the 316L stainless steel flat burner. The water-cooled fully premixed structure effectively prevents flame detachment and flashback by increasing the resistance of the combustion tray. The flat combustion tray is precisely matched with the coil heat exchanger, boosting heat exchange efficiency to 101.21%.
The water flow system operates simultaneously in both atmospheric and pressurized modes. In the atmospheric section, RO water from the cold water tank is preheated by a circulation pump in the condenser before being fed into the water-cooled burner for further heating, ultimately converging into the deaerated water tank. In the pressurized section, hot water from the deaerated water tank is pressurized by the pump set and enters the evaporator body, sequentially flowing through components such as the economizer and coils to be progressively heated into steam.
The flue gas flow follows a highly efficient heat exchange path: high-temperature flue gas generated by the combustion of mixed gases sequentially passes through the furnace, coils, economizer, and condenser to release heat. After cooling, it is discharged through the chimney, with the exhaust temperature consistently maintained below 50°C.
This equipment offers significant advantages: no inspection required, no permits needed, and no manual operation. It consumes ≤75m³ of gas per ton of steam produced per hour, with 100% steam dryness, a boiler thermal efficiency of up to 101.21%, and a maximum superheated steam temperature of 230°C. Nitrogen oxide emissions are ≤20mg/m³, while carbon monoxide emissions approach zero. It excels in energy efficiency, environmental protection, safety, and convenience, making it suitable for diverse industrial applications.
